Description

Brainboxes
Bluetooth to RS232 Serial
Adaptor 1 Port Male BL-819

1x Port Male RS-232 Bluetooth to Serial Adaptor
Data rate from 110 to 921,600 baud
Optional Power on Pin 9
Suitable for ANY device with a serial port
Range, Field: 30m, Office: 10m
Lifetime Support, 3 Year Warranty
BL-819-datasheet (0.60 MB)

Compact, Award winning Brainboxes RS232 Adaptor (BL-819 – male connector or BL-830 female connector) allows any
device with an RS232 port to communicate with another Bluetooth device without the need for any additional software.
Ideal for Bluetooth enabling dumb RS232 devices such as dataloggers etc. with option to power from Pin 9.
Based on fully tested Bluetooth silicon, allowing communications at the full Bluetooth data rates. No visible antenna.

Tech Spec
Serial Port
Ports 1
Protocol RS232
Connector DB9 Connector – 9 Pin Male
Tx FIFO Size 128
Rx FIFO Size 128
Operating Distance EIA – RS232 Standard
Cable
Serial Port Settings
Max Baud Rate 1,000,000 (1 MegaBaud)
Data Bits 8
Parity Odd, Even, None, Mark or Space
Stop Bits 1, 1.5 or 2
Flow Control XON/XOFF Software handshake or RTS/CTS hardware handshake
Tx/Rx Modes Point to Point
Bluetooth Settings
Bluetooth Qualification 1.1 Qualified
Bluetooth Class Class 2
Bluetooth Flow Control DTR/DSR
Radio Frequency 2.45 GHz
Supported Bluetooth Profiles SPP (Serial Port Profile)
General
PCB Layers 4
Storage Temperature -40 °C to +85 °C / -40 °F to +185 °F
Power Consumption Depends on usage
Product Weight 0.034 kg, 1.20 ounces
Product Dimensions 90 x 37 x 18 mm, 3.5 x 1.5 x 0.7 inches
Packaged Weight 0.368 kg, 12.98 ounces
Packaged Dimensions 200 x 135 x 80 mm, 7.9 x 5.3 x 3.1 inches
GTIN (Barcode) 837324000054
Operating System Compatibility
Operating Systems
Suitable for any device with Serial Port
Interface
Bluetooth Bluetooth

Please note

The above item(s) have been checked, to see if they carry the correct power output to match the manufactures shown output.
All items(s) have been tested

USED VERSION
